SBC - Total linear motion solutions


SBC - a competent specialist in the field of linear technology.

The company has been producing linear motion solutions since 1995.

Today's program includes ball rail guides, roller rail guides, ball screws and support units, longitudinal guides and guides for robot technology.

In terms of quality, SBC is at a high level, as proven by numerous awards, certifications, patents, but above all by well-known customers such as Doosan, GE, Hitachi, Honda, Hyundai-KIA, Mazda, Mitsubishi, Nissan, Kumhotire, Samsung, Suzuki, Toyota and others.

CMT offers all SBC products.

Manufacturer Articles

SBI20-SL-K1
SBI20-SL-K1
Design: block carriage | Size: 20 | Width: 44 | Height: 25,4 | Height on rail: 30 | Lenght: 78,8 | Preload: light preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, block design in standard length, SBC

€45.02*
SBI15-FL-K1
SBI15-FL-K1
Design: flange carriage | Size: 15 | Width: 47 | Height: 21 | Height on rail: 24 | Lenght: 63,8 | Preload: light preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, flange design in standard length, SBC

€44.54*
SBI45-FLL-K1
SBI45-FLL-K1
Design: flange carriage | Size: 45 | Width: 120 | Height: 51 | Height on rail: 60 | Lenght: 174 | Preload: light preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, long flange design, SBC

€146.64*
SBI35-FL-K1
SBI35-FL-K1
Design: flange carriage | Size: 35 | Width: 100 | Height: 40,5 | Height on rail: 48 | Lenght: 124,6 | Preload: light preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, flange design in standard length, SBC

€84.46*
SBI15-SL-K1
SBI15-SL-K1
Design: block carriage | Size: 15 | Width: 34 | Height: 25 | Height on rail: 28 | Lenght: 63,8 | Preload: light preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, block design in standard length, SBC

€44.54*
SBI15-FL-K2
SBI15-FL-K2
Design: flange carriage | Size: 15 | Width: 47 | Height: 21 | Height on rail: 24 | Lenght: 63,8 | Preload: medium preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, flange design in standard length, SBC

€45.87*
SBI15-SL-K2
SBI15-SL-K2
Design: block carriage | Size: 15 | Width: 34 | Height: 25 | Height on rail: 28 | Lenght: 63,8 | Preload: medium preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, block design in standard length, SBC

€45.87*
SBI15-HL-K1
SBI15-HL-K1
Design: block carriage | Size: 15 | Width: 34 | Height: 21 | Height on rail: 24 | Lenght: 63,8 | Preload: light preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, flat block design in standard length, SBC

€44.54*
SBI15-HL-K2
SBI15-HL-K2
Design: block carriage | Size: 15 | Width: 34 | Height: 21 | Height on rail: 24 | Lenght: 63,8 | Preload: medium preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, flat block design in standard length, SBC

€45.87*
SBI20-FL-K1
SBI20-FL-K1
Design: flange carriage | Size: 20 | Width: 63 | Height: 25,4 | Height on rail: 30 | Lenght: 78,8 | Preload: light preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, flange design in standard length, SBC

€45.02*
SBI20-FL-K2
SBI20-FL-K2
Design: flange carriage | Size: 20 | Width: 63 | Height: 25,4 | Height on rail: 30 | Lenght: 78,8 | Preload: medium preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, flange design in standard length, SBC

€46.38*
Sold out
SBI20-SLL-K1
SBI20-SLL-K1
Design: block carriage | Size: 20 | Width: 44 | Height: 25,4 | Height on rail: 30 | Lenght: 96,4 | Preload: light preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, long block design, SBC

€51.78*
Details
SBI20-SLL-K2
SBI20-SLL-K2
Design: block carriage | Size: 20 | Width: 44 | Height: 25,4 | Height on rail: 30 | Lenght: 96,4 | Preload: medium preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, long block design, SBC

€53.35*
SBI20-SL-K2
SBI20-SL-K2
Design: block carriage | Size: 20 | Width: 44 | Height: 25,4 | Height on rail: 30 | Lenght: 78,8 | Preload: medium preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, block design in standard length, SBC

€46.38*
SBI25-FL-K1
SBI25-FL-K1
Design: flange carriage | Size: 25 | Width: 70 | Height: 30,5 | Height on rail: 36 | Lenght: 92 | Preload: light preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, flange design in standard length, SBC

€57.43*
SBI25-FL-K2
SBI25-FL-K2
Design: flange carriage | Size: 25 | Width: 70 | Height: 30,5 | Height on rail: 36 | Lenght: 92 | Preload: medium preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, flange design in standard length, SBC

€59.16*
SBI25-SL-K1
SBI25-SL-K1
Design: block carriage | Size: 25 | Width: 48 | Height: 34,5 | Height on rail: 40 | Lenght: 92 | Preload: light preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, block design in standard length, SBC

€57.43*
SBI25-SL-K2
SBI25-SL-K2
Design: block carriage | Size: 25 | Width: 48 | Height: 34,5 | Height on rail: 40 | Lenght: 92 | Preload: medium preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, block design in standard length, SBC

€59.16*
SBI25-HL-K1
SBI25-HL-K1
Design: block carriage | Size: 25 | Width: 48 | Height: 30,5 | Height on rail: 36 | Lenght: 92 | Preload: light preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, flat block design in standard length, SBC

€57.43*
SBI25-HL-K2
SBI25-HL-K2
Design: block carriage | Size: 25 | Width: 48 | Height: 30,5 | Height on rail: 36 | Lenght: 92 | Preload: medium preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, flat block design in standard length, SBC

€59.16*
SBI25-FLL-K1
SBI25-FLL-K1
Design: flange carriage | Size: 25 | Width: 70 | Height: 30,5 | Height on rail: 36 | Lenght: 108 | Preload: light preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, long flange design, SBC

€72.35*
SBI25-FLL-K2
SBI25-FLL-K2
Design: flange carriage | Size: 25 | Width: 70 | Height: 30,5 | Height on rail: 36 | Lenght: 108 | Preload: medium preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, long flange design, SBC

€74.53*
SBI30-FL-K1
SBI30-FL-K1
Design: flange carriage | Size: 30 | Width: 90 | Height: 35 | Height on rail: 42 | Lenght: 107,6 | Preload: light preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, flange design in standard length, SBC

€65.21*
SBI30-FL-K2
SBI30-FL-K2
Design: flange carriage | Size: 30 | Width: 90 | Height: 35 | Height on rail: 42 | Lenght: 107,6 | Preload: medium preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, flange design in standard length, SBC

€67.18*
SBI30-SL-K1
SBI30-SL-K1
Design: block carriage | Size: 30 | Width: 60 | Height: 38 | Height on rail: 45 | Lenght: 107,6 | Preload: light preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, block design in standard length, SBC

€65.21*
SBI30-SL-K2
SBI30-SL-K2
Design: block carriage | Size: 30 | Width: 60 | Height: 38 | Height on rail: 45 | Lenght: 107,6 | Preload: medium preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, block design in standard length, SBC

€67.18*
SBI30-FLL-K1
SBI30-FLL-K1
Design: flange carriage | Size: 30 | Width: 90 | Height: 35 | Height on rail: 42 | Lenght: 131,6 | Preload: light preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, long flange design, SBC

€82.14*
SBI30-FLL-K2
SBI30-FLL-K2
Design: flange carriage | Size: 30 | Width: 90 | Height: 35 | Height on rail: 42 | Lenght: 131,6 | Preload: medium preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, long flange design, SBC

€84.59*
SBI30-SLL-K1
SBI30-SLL-K1
Design: block carriage | Size: 30 | Width: 60 | Height: 38 | Height on rail: 45 | Lenght: 131,6 | Preload: light preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, long block design, SBC

€80.85*
SBI30-SLL-K2
SBI30-SLL-K2
Design: block carriage | Size: 30 | Width: 60 | Height: 38 | Height on rail: 45 | Lenght: 131,6 | Preload: medium preload | Precision class: normal | Sealing: standard | Material: standard | Cage: full-complement
Runner block, Recirculating ball bearing and guideway assemblies, long block design, SBC

€83.27*
